Specken-Drumag氣動缸RP500簡介

吳亞男 QQ：2853369884   手機：17718583804 電話：010-64714988-212 傳真：010-64714988-668 郵件：tk2@handelsen.cn

Specken-Drumag氣動缸RP500簡介

工作壓力：1.5÷10 bar

環境溫度：-20÷80°C。

流體：過濾空氣，有或沒有潤滑。

桶：內部/外部陽極氧化鋁和

孔：KD系列32÷125鋁桶

系列K 160÷200，帶圓形鋁桶和鋼制拉桿

嵌入式磁傳感器DF ---- KD系列系列。

Specken-Drumag氣動缸RP500簡介

電線保護帶磁傳感器

適用于KD系列零件編號DHF-002100。

符合ISO 6431和VDMA 24562標準的UNIVER氣缸，充分利用了過去幾年的研究成果; 事實上，他們可以完全滿足苛刻的用戶。 使用非潤滑空氣的操作是值得的，因為它允許在許多工業部門中使用

保護環境。 強大的結構和選定的部件有助于賦予它們出色的操作性能和非常長的使用壽命。

嵌入式磁傳感器DF ---- KD系列系列。

電線保護帶磁傳感器

適用于KD系列

磁傳感器DH ---- K系列系列。

根據要求

- 塑性鐵氧體中的磁環

- 鎖定裝置?32÷125 mm，僅可與鍍鉻鋼棒系列KD

- 滑動裝置?32÷100 mm

- 帶有剛性襯套的氣缸，串聯，多位置和對置型

施工細節

采用擠壓鋁合金制成的清潔線桶，采用羅紋“抗扭”設計。內外表面陽極氧化至15微米。

鋁合金壓鑄端蓋采用自攻鋼螺釘安裝在機筒孔上。

氣動可調緩沖墊提供有效的活塞減速。

合成橡膠減震器可避免機械應力并降低機械噪音(低于50 dB)。

采用乙縮醛樹脂壓鑄鋁合金活塞和導靴，帶永久塑性鐵氧體磁環(根據要求提供磁性版本)。

活塞和緩沖密封件由耐磨的丁腈橡膠復合材料制成，適用于有或沒有的應用

潤滑。雙唇密封設計可自動自我補償磨損。

硬化不銹鋼棒(KD100系列)或鍍鉻(KD200系列)，2微米Ra;提供堅果。

UNIVER原裝自潤滑自調心活塞桿襯套。對于特殊應用，可根據要求提供剛性襯套。氣缸?125-160-200，提供標準的剛性活塞桿襯套。

Specken-Drumag液壓氣缸產品分類：

Specken-Drumag RIBA比例控制器

Specken-Drumag 液壓缸

Specken-Drumag Specken-Drumag 液壓氣動系統

Specken-Drumag speedPOWER - 按壓氣缸

Specken-Drumag speedPOWER - 電動缸

Specken-Drumag 電動缸

Specken-Drumag 氣動缸

Specken-Drumag 旋轉執行器

Specken-Drumag 閥門

Specken-Drumag 壓縮機/ Vacuumpumps

Specken-Drumag 壓縮空氣處理

Specken-Drumag 氣動馬達

Specken-Drumag 消音器

Specken-Drumag RS200

Specken-Drumag 80 ZLS

Specken-Drumag 3V4-EF-V

Specken-Drumag ZLA-C-SHA 50/60-D-N

Specken-Drumag RP500

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag ZHS-A 36

Specken-Drumag RP300

Specken-Drumag R41-CB-R00

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag 4AM-FRV-63A

Specken-Drumag 4AM-NRV-22B-P120.

SPECKEN-DRUMAG液壓氣缸型號：

ZAR系列：

ZAR-FBv 25/125 NHR15 D-U01 E31，

ZU系列：

ZU-Fv 32/140 NHR16 D-H03 E11g G1/4“ ES As4，

ZISO/T系列：

ZISO/T-RFv 32漢18達250 Dbb森H03 E22 ES，

ZU,250系列：

ZU250-G

ZHSS系列

主要產品介紹：

Hydaira液壓氣缸：

ZAR系列(活塞直徑10-25mm,工作壓力至63bar，6種密封模式，6種固定方式，不銹鋼)

ZU系列(活塞直徑10-100mm,工作壓力至100bar，8種密封模式，12種固定方式)

ZISO/T系列(活塞直徑25-100mm,工作壓力至160bar，4種密封模式，11種固定方式)

ZU250系列(活塞直徑20-100mm,工作壓力至250bar，4種密封模式，11種固定方式)

ZHSS系列(活塞直徑16-50mm,工作壓力至400bar，原型緊湊結構，3種固定方式)

氣動氣缸：

氣動伸縮式氣缸(兩級和三級，直徑32-63mm,雙向作用，6bar時大活塞力為750N)

帶測距系統的氣缸

氣缸(M系列迷你氣缸8 ÷ 25 mm，Z系列八角迷你氣缸16 ÷ 25 mm，32 ÷ 63 mm，K/KD系類氣缸32 ÷200 mm，R系列旋轉驅動32 ÷ 125 mm，RP/RO緊湊型氣缸32 ÷ 63 mm，RS/PQ系列緊湊型氣缸，RT系列兩級和三級伸縮式氣缸 32 ÷ 63 mm，W系列短行程缸 12 ÷ 100 mm，OV系列橢圓形氣缸 50 ÷ 63 mm)

閥門：

B系列納米閥門 10mm

A系列微型閥門 15mm

AA/AB系列微型先導閥2/2 - 3/2

AC系列螺紋連接閥門MIXED 5/2 DN
