Duplomatic壓力控制閥CR系列簡介

 Duplomatic壓力控制閥CR系列簡介

CR 直動式壓力控制閥 序列號 22

插裝式 高工作壓力 350 bar 大流量 50 l/min

工作原理

— CR型閥是一種插裝式直動型壓力控制閥，它可安裝在符合 D-10B閥座孔的集成塊或閥板上。

— 該閥通常用于控制液壓回路的大壓力，也可用于限制液 壓油缸(馬達)運動變化過程中產生的峰值壓力。

— 該閥具有5種不同的壓力調整范圍，大壓力 350 bar。

— 作用到該閥上的回路壓力與彈簧力相平衡。當達到設定的 壓力時，該閥打開，多余油液通過T口直接回油箱。 — 可通過調整螺釘設定壓力。通常使用沉頭內六角螺釘形式，同時裝有鎖緊螺母和大調節限位器



Duplomatic壓力控制閥CR系列簡介

技術參數 (在油溫 50°C，油液粘度 36 cSt條件下測得)

大工作壓力 bar 350

大流量 l/min 50

環境溫度范圍 °C -20 / +50

油液溫度范圍 °C -20 / +80

油液粘度范圍 cSt 10 ÷ 400

油液允許的高污染等級 根據 ISO 4406：漢1999 等級 20/達18/15

推薦油液粘度 cSt 25

質量 kg 0,16

表面鍍鋅處理 Fe // Zn 8 // B EN 12329

Duplomatic EDM - M 1111NE01

Duplomatic EDM - M 1111NE02

Duplomatic EDM - M 2111NE01

Duplomatic EDM - M 2111NE02

Duplomatic EDM - M 3111NE01

Duplomatic EDM - M 3111NE02

Duplomatic EDM - M 1211NE01

Duplomatic EDM - M 1211NE02

Duplomatic EDM - M 1311NE01

Duplomatic EDM - M 1311NE02

Duplomatic EDM - M 1411NE01

Duplomatic EDM - M 1411NE02

Duplomatic EDM - M 1511NE01

Duplomatic EDM - M 1511NE02

Duplomatic EDM - M 1121NE01

Duplomatic EDM - M 1121NE02

Duplomatic EDM - M 1131NE01

Duplomatic EDM - M 1131NE02

Duplomatic EDM - M 1141NE01

Duplomatic EDM - M 1141NE02

Duplomatic EDM - M 1112NE01

Duplomatic EDM - M 1112NE02

Duplomatic EDM - M 1113NE01

Duplomatic EDM - M 1113NE02

Duplomatic EDM - M 1114NE01

Duplomatic EDM - M 1114NE02

Duplomatic EDM - M 2222NE01

Duplomatic EDM - M 2222NE02

Duplomatic EDM - M 2322NE01

Duplomatic EDM - M 2322NE02

Duplomatic EDC-112 24V DC

Duplomatic EDC-142 12V DC

Duplomatic EDM-M112 24V DC

Duplomatic DIN EN 50022

Duplomatic CRE-140/20ND12K1

Duplomatic CRE-70/20ND12K1

Duplomatic CRE-250/20ND12K1

Duplomatic CRE-140/20ND24K1

Duplomatic CRE-70/20ND24K1

Duplomatic CRE-250/20ND24K1

Duplomatic CRE-140/20vD24K1

Duplomatic CRE-70/20vD24K1

Duplomatic CRE-250/20vD24K1

Duplomatic DSE 3-SA/11vD24K1

Duplomatic DSE 3-SB/11vD24K1

Duplomatic DSE 3-SA/11ND24K1

Duplomatic DSE 3-SB/11ND24K1

Duplomatic DSE 3-SA/11vD12K1

Duplomatic DSE 3-SB/11vD12K1

DUPLOMATIC QTM5-D/10N

DUPLOMATIC CHM5-D/10N

DUPLOMATIC DS5-S3/12N-D24K1

DUPLOMATIC DS5-S1/12N-D24K1

DUPLOMATIC Dentex B48.H7-40H7 Si

DUPLOMATIC DSE3J-Z30/20N-E0K11

DUPLOMATIC DSPE5G-A80/11N-ZI/E1K11/B1比例閥

DUPLOMATIC EDC-112/10E0電磁閥

DUPLOMATIC RPCED1-25/C/51-24電磁閥

DUPLOMATIC PRR-40-ER32/50-T

DUPLOMATIC PRR-40-ER32/40-T

DUPLOMATIC RPR-40-ER32/40-E

DUPLOMATIC R2-I1

DUPLOMATIC VR5-I1

DUPLOMATIC VR7-I1

DUPLOMATIC VR2-I3

DUPLOMATIC VR5-I3

DUPLOMATIC VR7-I3

DUPLOMATIC VR2-I4

DUPLOMATIC VR5-I4

DUPLOMATIC VR7-I4

DUPLOMATIC VD2-W

DUPLOMATIC VD3-W

DUPLOMATIC VD4-W

DUPLOMATIC VD5-W

DUPLOMATIC VD6-W

DUPLOMATIC VD7-W

DUPLOMATIC VD8-W

DUPLOMATIC VD9-W

DUPLOMATIC VR3-P1

DUPLOMATIC VR3-P3

DUPLOMATIC VR3-P4

DUPLOMATIC VR5-P1

DUPLOMATIC VR5-P3

DUPLOMATIC VR5-P4

DUPLOMATIC VR7-P1

DUPLOMATIC VR7-P3

DUPLOMATIC VR7-P4

DUPLOMATIC MVR1-SP

DUPLOMATIC MVR1-SA

DUPLOMATIC MVR1-SB

DUPLOMATIC MVR1-ST

DUPLOMATIC MVR1-SPT

DUPLOMATIC MVR3-SP

DUPLOMATIC MVR3-SA

DUPLOMATIC MVR3-SB

DUPLOMATIC MVR3-ST

DUPLOMATIC MVR3-SPT

DUPLOMATIC MVR-RS/P/50

DUPLOMATIC MVPP-SA

DUPLOMATIC MVPP-SB

DUPLOMATIC MVPP-D

DUPLOMATIC VPP4M-SA

DUPLOMATIC VPP4M-SB

DUPLOMATIC VPP4M-D

DUPLOMATIC CHM7-D

DUPLOMATIC CHM7-SA

DUPLOMATIC CHM7-SB

DUPLOMATIC VP3-W2P-MU

DUPLOMATIC VP5-W2P-MU

DUPLOMATIC VP3-W3P-MU

DUPLOMATIC VP5-W3P-MU

DUPLOMATIC VP3-P2P-MU

DUPLOMATIC VP5-P2P-MU

DUPLOMATIC VP3-P3P-MU

DUPLOMATIC VP5-P3P-MU

DUPLOMATIC DS5-S3/12N-A110K1

DUPLOMATIC DS5-S3/12N-A00

DUPLOMATIC DS5-TB/10N-A00

DUPLOMATIC DS3-S3/10N-A110K1

DUPLOMATIC DS3-S1/10N-A110K1

DUPLOMATIC DS3-S4/10N-A00

DUPLOMATIC DS3-SA1/10N-A00

DUPLOMATIC DS3-TB/10N-A00

DUPLOMATIC DS3-RK/10N-D00

DUPLOMATIC DS3-TB23/10N-A00

DUPLOMATIC DS3-SB1/10N-A00

DUPLOMATIC DS3-SB11/10N-A00

DUPLOMATIC DS3-S2/10N-D12K1/CM

DUPLOMATIC DS3-S21/10N-D00-CC

DUPLOMATIC DS3-RK/10N-A230K1 DS3-S2/10N-A00-CA

DUPLOMATIC DS3-S2/10N-A24K1

DUPLOMATIC DS3-S3/10N-A00-CA

DUPLOMATIC DS3-S1/10N-D24K1

DUPLOMATIC DS3-S1/10N-D00-CC

DUPLOMATIC DS3-S4/10N-A110K1

DUPLOMATIC DS3-S2/10N

DUPLOMATIC DS3-S3/10N-D00-CC

DUPLOMATIC DS3-S4/10N-D00

DUPLOMATIC DS3-TB/10N-D110K1

DUPLOMATIC DS3-TA/10N-D00-CC

DUPLOMATIC DS3-TB/10N-D00-CC

DUPLOMATIC DS3-RK/10N-D110K1

DUPLOMATIC DS3-TA/10N-A00-CA

DUPLOMATIC DS3-SA2/10N-D00-CC

DUPLOMATIC DS3-S1/10N-

DUPLOMATIC D12K1/CM DS3-TB/10N-110

DUPLOMATIC DS3-RK/10N-A00

DUPLOMATIC DS3-RK/10N-A110K1

DUPLOMATIC DS3-SA2/10N-D12K1/CM

DUPLOMATIC DS3-RK/10N-D24K1

德國Deutronic電機控制器d-IPS1000C-24技術規格

d-IPS1000C-24

技術參數：

輸入電壓：100-240VAC

輸出電壓：0-30VDC / 24VDC

電流：0-40A / 0,1A

特點

· 輸入AC 100-240V，有源PFC范圍廣

· IEC 6095A0-1，EN 6095B0-1，UL 609C50-1，CSA 22.2 No. 609V50-1，UL 508，

IEC 62103，EN 50178，IEC 60D204-1

· EMC：EN 55011 B類，EN 6100E0-3-2，EN 6100F0-6-2，EN 6120G4-3

· 廣泛的功率輸出保護：

短路，空載，過壓，過熱

· 極低的待機功率，高效率(在整個輸入電壓范圍內的平滑行為)

· 沒有浪涌電流

· 浮動繼電器觸點

· 數字輸入/輸出，模擬輸入(0-10 V或4-20 mA)

· 接口：RS-232
